then you can type the name of the desired style (which also changes the current text style) to use for the new MTEXT object.you can right-click in the drawing after picking the first corner point to invoke a shortcut and select Style.

the current style is displayed on the command line when you invoke Mtext.The current text style is used for new MTEXT objects in the same way text styles are used in TEXT objects.

#Autocad double click text edit how to#

See also How to use ZOOM & PAN In Real Time commands

characters are UPPER CASE as you type regardless of the Caps Lock setting on your keyboard when AutoCAPS is On.

double-click on the AutoCAPS pane to toggle this setting On or Off.

You can force characters typed in the Multiline Text Editor to always be UPPER CASE by turning on AutoCAPS

you must select the desired characters that you have already typed & then specify the desired height in this drop-down list.

If you have already typed characters in the editor then these characters will not change when you change the text height value.

you can select a height in the drop-down list or you can type a value for the desired height there instead.

this overrides the current default for text height without changing the TEXTSIZE system variable used in the next Mtext command.

You can also change the value for height in the drop-down list of the Multiline Text Editor BEFORE you type any characters.

right-click in the drawing area at the prompt for the opposite corner & select Height from the shortcut to change TEXTSIZE.

the current height is displayed on the command line when you invoke Mtext.

The default Height of MTEXT is controlled by the same TEXTSIZE system variable that sets the default TEXT height for Dtext.

when word wrapping is Off you must press the key to begin new lines (as new paragraphs) in the current MTEXT.

you can also use this approach to enter a value of zero for Width to explicitly turn word wrapping Off.

use this approach when you know the required width or it is not convenient to pick another corner point to control the width.

You can also pick one corner point & right-click in the drawing area to select Width from a shortcut instead of picking the other corner.

width is calculated from the opposite corners of the bounding box (the horizontal distance) if you pick two corner points.

The Width of an MTEXT object determines how long a line of text can be before the next line begins automatically.

for example, BR is the abbreviation for Bottom Right.

right-click again and select a two letter abbreviation for the desired justification in another shortcut.

You can right-click in the drawing area at the prompt for the opposite corner and select Justify from the shortcut.

justification determines how characters are aligned with this box & whether text flows out of the top or the bottom of the box.

characters are allowed to flow out of the bounding box as you type more lines for the current MTEXT object.

The bounding box is displayed only while you are picking the two corners of this box or when you edit an MTEXT object with grips. Pick two points to use the default Mtext options and define opposite corners for a bounding box of the new MTEXT object.Ĭurrent text style: “Layout Notes” Text height: 0.1250

use Find/Replace tab to find and replace characters in the MTEXT object that is currently loaded in the editor.

You can change settings for an entire MTEXT object from the Properties and Line Spacing tabs in this editor.

select the desired text in the editor & select the desired format from the Character tab to change the selected characters.

#Autocad double click text edit windows#

Mtext lets you format characters individually using familiar Windows techniques in the Multiline Text Editor.

use the Mtext command to create MTEXT objects.

You can create entire paragraphs (multi lines) of text as a single MTEXT object and each character can be formatted separately.

#Autocad double click text edit free#

Free course how to use Multiline MTEXT Objects in AutoCAD
